Liebherr-Werk Ehingen GmbH is putting a new system into operation to add the final paint to its large crawler crane components. The system meets the latest environmental protection, occupational safety, and paint application requirements, including filters and heat recovery systems. Mobile work platforms and height securing devices are used to optimize occupational safety and ergonomics.
The company’s increased crawler crane lineup and larger components call for added painting capacity. A new painting hall has been established where the the complete painting process can be carried out. A standard workflow was already defined during the planning: After testing the prime-coated crawler crane on the acceptance grounds, the individual components are cleaned and masked in the new painting hall. Components not meant to be painted, like sensors, are masked. This is followed by final painting and drying in four painting boxes. Manufacturing is then performed in a special area of the factory.
“The time intervals have shifted in recent years,” said Thomas Nüssle, division manager. “The actual painting still takes only about a third of the entire work process. The preparation and completion meanwhile takes up significantly more resources in terms of time and space, which means we need more floor space for these activities. We needed to consider this together with rationalization measures as early as the planning phase.”
Nüssle said a further challenge when planning the new painting system was to introduce less harmful substances in the paints to meet current regulations. “Yet, at the same time, these paints are more difficult to work with. We’ve therefore invested a great deal in the technical system for paint application,” he said. To prevent deposits from accumulating in the tanks and lines, the paint is conveyed at low pressure in a ring line in the new system. The pressure is not increased until the painting cabin, where additionally installed high-pressure pumps are used for this – which means a tremendous painting quality can be realized with a constant pressure of about 160 bar.
Environmental protection was in focus when designing the new painting system. Filters with three-fold structure are used in the four painting boxes. A noteworthy fact is the air dissipated in the environment is even cleaner than the fresh air supplied in a modern passive house. The new painting system also requires less energy supply than conventional systems, as about 70 percent of the heat is recovered with a highly effective process of heat recovery.
Improved ergonomics and occupational safety were also important criteria in the planning. The stationary work platforms adjustable in three axes are installed in the new system, which the workers can use to move to optimal painting positions. In addition, the employees are secured with high securing devices. This is important because the components are sometimes very large and the employees work at considerable heights.
In the new system, Liebherr is working with a three-component system for the first time. Here up to 10 percent of the top coat to be applied later is added to the filler. In this way, color hues with poor coverage achieve a better covering capacity, thereby saving material and time.
The new painting system also offers the option of preserving components in a separate painting box with a special layer for extreme environments, such as salt water in the sea.
